Kenwood Dmx1038s 10.1 Hd Capacitive Screen Media Receiver, Screen Adjustments Include Vertical And Horizontal Settings, 1-din Chassis, Wireless Car...

General Operating voltage: 12V DC Car Battery Set Weight: 2.5Kg/ 5.6lb Chassis Dimensions WxHxD: 178mm x 50mm x 158mm/ 7 x 2 x 6-1/4 inch Weight: 1.3kg/ 2.9lb Monitor Dimensions WxHxD: 262mm x 181mm x 52mm/ 10-5/16 x 7-1/8 x 2-1/16 inch Weight: 1.1Kg/ 2.4lb Monitor Section Picture size: 10.1 inches(diagonal) wide W x H: 223.7 x 125.8 (mm), 8-13/16 x 4-15/16 (inch) Display system: LCD panel Drive system: TFT active matrix system Number of pixels: 2,764,800, 1280H x 720V x RGB Effective pixels: 99.99% Pixel arrangement: RGB striped arrangement USB I/F Section Connector Type: Type-C USB Standard: USB2.0 High Speed File System: FAT 16/32, exFAT, NTFS Maximum Power Supply Current: DC5V=3.0A Audio Decoder: MP3 / WMA / AAC / WAV / FLAC / Vorbis Video Decoder: MPEG1/2,MPEG4 / WMV / H.264 / MKV Bluetooth Section Technology: Bluetooth Ver5.2 Frequency: 2.402 – 2.480 GHz Maximum Communication range: Line of sight approx. 10m (32.8ft) Audio Codec: SBC / AAC / LDAC Digital FM Frequency Range: 87.9MHz - 107.9MHz (Frequency step)(200kHz) Frequency Response: 20Hz - 20kHz (±3.0 dB) S/N: 80dB (STEREO) Digital AM Frequency Range: 530kHz - 1700kHz (Frequency step)(10kHz) Frequency Response: 40Hz - 15kHz (±3.0 dB) S/N: 80dB (STEREO) FM Frequency Range: 87.9MHz - 107.9MHz (Frequency step)(200kHz) Usable sensitivity: 7.3dBf S/N 30dB: 0.7μV/75Ω Frequency response (±3.0dB): 30Hz - 15kHz S/N(dB): 70dB (MONO) Selectivity: Over 80dB (±400kHz) Stereo separation: 45dB (1kHz) AM Frequency Range: 530kHz - 1700kHz (Frequency step) (10kHz) Usable sensitivity: 30dBμ Video Color system of external video input: NTSC/PAL External video input level (RCA jacks): 1 Vp-p / 75 Ohms Video Input level (RCA jacks): 1 Vp-p / 75 Ohms Audio Maximum Power Output (Front&Rear): 50Wx4 Typical Power Output (Front&Rear): 29W x 4 (4Ω,1kHz,10%THD) Output frequency band: 20 - 88,000Hz Preout level (V): 5V / 10kOhms Preout impedance (Ω): =< 300 Ohms Speaker Impedance (Ω): 4-8 Ohms
